PREVOST H3-45 2023 User Manual

4-72 Controls and Instruments
PA-1652 Operator's Manual H3-45 Coach
SIDE CAMERA REAR VIEW MONITORS
FIGURE 51: MONITOR
CAUTION
Do not cover the cooling vents on the back of the
monitor.
REFERENCE LINES
Upon activation of the turn signals, three
reference lines appear on the main view of the
corresponding monitor (see image below). When
in reverse, two reference lines (yellow & red) are
displayed on both monitor.
FIGURE 52: REFERENCE LINES IN MONITOR
FIGURE 53: REFERENCE LINES
BRIGHTNESS ADJUSTMENT
Each monitor switches automatically and
independently between night mode and day
mode depending on the actual ambient light.
However, the driver can adjust the brightness
with the brightness control at the bottom of the

PREVOST H3-45 2023 Specifications

General

Manufacturer	Prevost
Model	H3-45
Year	2023
Category	Buses
Engine	Volvo D13
Horsepower	500 hp
Length	45 ft
Width	102 in
Seating Capacity	56 passengers
Air Conditioning	Yes
GVWR	54, 000 lbs
Entertainment System	Available
