16 - Coach Exterior -
PA-1652 Operator's Manual H3-45 Coach
FIGURE 27: EVAPORATOR COMPARTMENT
The evaporator compartment contains relays,
diodes and a multiplex electronic module
mounted on a panel located on top of the fan
assembly.
FIGURE 28: HVAC PANEL
NOTE
It is important to keep the evaporator
compartment door closed while checking the
HVAC system to prevent faulty readings.
STREET SIDE FUEL FILLER NECK
ACCESS
Open this access hatch with the exterior
compartment key.
FIGURE 29: FUEL FILLER NECK ACCESS HATCH LOCK
FIGURE 30: STREET SIDE FUEL FILLER NECK
NOTE
Provided the vehicle is parked on level ground,
an automatic nozzle will automatically shut off
when tank is approximately 95% full.
CAUTION
Do not fill to more than 95% of the fuel tank
capacity. Do not "top off" the fuel tank, doing so
may result in fuel spillage when the fuel expands.
