3-10 Coach Interior
PA-1652 Operator's Manual H3-45 Coach
FIGURE 17: SUNSHADE
Two electrically- operated sunshades are
installed at the windshields. Two rocker switches
on the dashboard operate each sunshade
individually. Refer to “Controls and Instruments”
chapter for more information.
CAUTION
The electric sunshades should only be
operated electrically. Pulling down manually
may damage the mechanism.
VENTILATION / EMERGENCY EGRESS
HATCHES
A ventilation hatch may be installed in the ceiling
at the rear of the coach. A second, optional hatch
can be installed on the roof at the front of the
coach. To open the hatch, push up with both
hands and pull down to close. The ventilation
hatch can be completely opened for emergency
egress. Refer to “Safety Features and
Equipment”.
FIGURE 18: VENTILATION HATCH
WARNING
Be aware of coach overhead clearance when
traveling under overpasses with the ventilation
hatch(es) open. Check for maximum clearance
height.
OVERHEAD COMPARTMENTS
Passenger carry- on baggage is stored in
overhead compartments on each side of the
coach. A first aid kit is located in the first front
curb side overhead storage compartment.
A media player may be installed in the first front
driver’s side overhead storage compartment.
To open the optional closed overhead storage
compartments, push the handle in to release the
latch, then let go. A pressurized cylinder opens
the door.
NOTE
The overhead storage compartments have a
minimum amount of separators installed so as
to quicken inspection for forgotten objects.
NOTE
An optional lock can be installed on the first
front driver’s side overhead storage
compartment door.
FIGURE 19: OVERHEAD STORAGE COMPARTMENTS
WASTE CONTAINER
The waste container is located on the lavatory
wall, and is accessible through an opening on
each side of the wall. A small door, located on the
