Coach Exterior - 15
PA-1652 Operator's Manual H3-45 Coach
convex- type rear- view mirrors appear smaller
and are actually closer than they appear.
To provide good visibility in cold weather, the
mirrors can be equipped with heating elements.
The elements are activated by a rocker switch
located on the dashboard. Refer to "Controls &
Instruments" chapter. Thermostats are used to
prevent continuous operation of the heating
elements.
CAUTION
Do not attach stick- on type convex mirror
accessories to the heated mirror glass. This could
impede uniform heat distribution on the mirror
surface and could break the mirror glass.
As an option, the mirrors may be equipped with
LED turning signal lights to give an additional
signal light when turning or changing lane for
extra safety or for other drivers to see your signal
when driving too close, in rain, fog or when in
blind spot.
The mirrors are adjusted using the controls
located on the lateral control panel. Refer to
"Controls & Instruments" chapter.
Adjust the side-view mirrors until the side of the
vehicle is visible. Adjust the flat-type mirror until
the road behind is in full view.
SIDE CAMERA REAR VIEW SYSTEM
The vehicle may be equipped with optional video
camera mirror system. To provide good visibility
in cold weather, the camera lens shield is
equipped with heating elements. The heating
elements are activated by a rocker switch located
on the dashboard. Refer to "Controls &
Instruments" chapter.
CAUTION
To avoid damage to the heating system, the
heating elements shall not be permanently
activated.
FIGURE 25: L.H. SIDE CAMERA
EVAPORATOR COMPARTMENT
To access the evaporator compartment, pull the
release latch located on the left side wall of the
rearmost baggage compartment.
FIGURE 26: EVAPORATOR COMPARTMENT ACCESS
