3-2 Coach Interior
PA-1652 Operator's Manual H3-45 Coach
UTILITY COMPARTMENTS
Two utility compartments are located at the R.H.
side of the dashboard. For other utility
compartments already covered in this manual,
refer to "LATERAL UTILITY COMPARTMENT"
on page5 and "CENTRAL UTILITY
COMPARTMENT" on page22.
FIGURE 1: UTILITY COMPARTMENT
DRIVER’S PERSONAL
COMPARTMENTS
A lockable compartment for the driver is located
on the L.H. side of the entrance stepwell. This
compartment may be locked using the
appropriate key. A tour guide seat is available as
an option and is installed in front of the driver’s
compartment on dedicated seat anchors.
FIGURE 2: DRIVER’S PERSONAL COMPARTMENT
MICROPHONE JACKS
Up to six microphone jacks for the PA system can
be located in the following locations:
l On the wall to the left of the driver;
l On the right hand side of the dashboard;
l One optional outlet for the tour guide on the
modesty panel;
l One optional outlet on the lavatory wall, behind
the last row of seats;
l One optional outlet under the overhead storage
compartment, at the rear of the coach.
DRIVER’S SEAT - ISRI
The vehicle can be equipped with one of two
models of ISRI driver's seats. Mechanically
adjusted seat and pneumatic model are
available. Both seats are equipped with safety
belts. Lumbar supports, heated cushions and
adjustable armrests are optional.
DANGER
The driver’s seat must be adjusted to allow the
driver easy access to the coach controls. Never
adjust seat while driving vehicle as this could
result in loss of vehicle control.
DANGER
Make sure that seat is adjusted and that safety
belt is buckled up before driving vehicle.
MECHANICAL ISRI SEAT
Adjustment
Seat can be adjusted to the desired driving
position by following the instructions listed below:
To Next Page
