DIMENSIONS AND WEIGHTS H3-45
Overall length (over bumpers) 45 ' 13 716 mm
Overall width 102 " 2 590 mm
Overall height (normal ride height) 148 " 3 759 mm
Wheelbase (front axle to drive axle) 313.4 " 7 960 mm
Floor height from ground 63 " 1 600 mm
Ground clearance 10 3/4 " 273 mm
Step height from ground 14 " 356 mm
Step height (other steps) 7 " 178 mm
Seats 56 - 58
Headroom 77 " 1 956 mm
Entrance door opening width 28 " 711 mm
Aisle width (minimum) 14 " 355 mm
Front overhang 75 " 1 909 mm
Rear overhang 108.37 " 2 753 mm
Front track 85.2 " 2 162 mm
Drive track 74.3" 1 887 mm
Rear track (tag axle) 83.8 " 2 128 mm
Curb weight (fuel tank full) 39 600 lbs 18 000 kg
Additional weight - wheelchair lift system 1 100 lbs 500 kg
Fuel Weight (full tank) 1 650 lbs 750 kg
Gross Vehicle Weight Rating (G.V.W.R.) 53 000 lbs 24 040 kg
Front axle Gross Axle Weight Rating (G.A.W.R.) 16 500 lbs 7 500 kg
Drive axle G.A.W.R. 22 500 lbs 10 205 kg
Tag axle G.A.W.R. 14 000 lbs 6 214 kg
NOTE
Curb weight is given as an indication only and is subject to vary from coach to coach, mostly due to optional
equipment
The actual Gross Vehicle Weight Rating (G.V.W.R.) and the Gross Axle Weight Rating (G.A.W.R.) for front,
drive and tag axles are listed on a certification plate located on the L.H. control panel in driver's section.
PA-1652 Operator's Manual H3-45 Coach
Technical Information 9-7
