8 A26361-K878-Z102-2-7619
Technical Data Introduction
Mechanical values
Weight
13 - 15 kg (depending on the configuration)
Ventilation clearance
at least 200 mm on the front and on the rear side
Environmental conditions
Condensation during operation must be avoided!
Noise level
Width 430 mm
Installation depth 650 mm
area for cable routing (cable area depth) in the rack 100 mm
Height 44.2 mm or 1 HU
Environment class 3K2
Environment class 2K2
EN 60721 / IEC 721 section 3-3
EN 60721 / IEC 721 section 3-2
Temperature:
Operation (3K2)
Transport (2K2)
5 °C .... 35 °C
-25 °C .... 60 °C
Humidity 10 ... 85%
Sound power level L
WAd
(ISO 9296) ≤ 7,3 B (standby)
≤ 7,5 B (operating)
Sound pressure level at bystander position
L
pAm
(ISO 9296)
≤ 58 dB(A) (standby)
≤ 60 dB(A) (operating)
