PRIMERGY RX200 - Operating and Indicator Elements; The Front

42 A26361-K878-Z102-2-7619
Operating and Indicator Elements Preparation for Use and Operation
5.3 Operating and Indicator Elements
5.3.1 The Front
Figure 16 shows the operating and indicator elements on the front.
Figure 16: The front
1 ID button 5 ON/OFF button
2 ID indicator 6 Power-on indicator
3 Global Error indicator 7 NMI button
4 Drive access indicator 8 Reset button
1
2
3
4
5
6
7
8
