Prinoth BISON X - Operating Fluids

Operating fluids
Operating fluids for the BISON
Specifications Note Quantity
ENGINE OIL
CAT DEO - ULS, CAT ECF-3, API CJ-4, ACEA E9.
The viscosity depends on the ambient temperature
(e.g., SAE 0W30, 5W30, 10W30, 10W40)
Initial filling CAT
ECF-3: 0W40.
32 l (8.45 US gal)
DIESEL FUEL and AdBlue® / DEF
Diesel fuel: EN 590, ASTM D975 N.1 D, Ultra Low
Sulfur Fuel only, S<15 ppm (mg/kg)
266 l (70.3 US gal)
AdBlue® / DEF: DIN 70700, ISO 22241-1 27 l (7.1 US gal)
ENGINE COOLING FLUID
Antifreeze/anticorrosion agent, 50 % antifreeze, 50 %
water
--------
CAT DEAC, Heavy-duty coolant according to ASTM
D4985 (use supplement coolant additive SCA at initial
fill) or ASTM D6210
For temperatures be-
low-35°C (-31°F),
contact the PRI-
NOTH Service de-
partment.
45 l (11.9 US gal)
HYDRAULIC OIL
ATF oil: Dexron III, Dexron II, Type F, Type A Suffix A
Biodegradable oil: Panolin HLP Synth 46, York
Bio 777 VG 46
130 l (34.3 US gal)
PUMP DRIVE OIL
Synthetic gear oil PAO basis (polyalphaolefin), Vis-
cosity: ISO 220, SAE 75W 90 or 75W 140, API GL-4
or GL-5
2,7 l (0.7 US gal)
FINAL DRIVE OIL
Synthetic gear oil PAO basis (polyalphaolefin), Vis-
cosity: ISO 220, API GL-4 or GL-5
(each)
1,8 l (0.5 US gal)
GREASE SPECIFICATION
AdBlue / DEF Filter sealing rings : MB-Silicon grease
------
Bearing and other lube points : Calcium or lithium
soap grease according to DIN 51825 KP 2G -30,
DIN 51502. For temperature below -30°C (-22°F) use
NLGI grade 1, EP rated (temperature
range -40°C (-40°F) to 100°C (212°F)).
-----
Power tiller spline coupling : Anorganic grease ac-
cording to DIN 51825 MPF 1/2U - 30, DIN 51502
(NLGI grade 1/2, EP rated, temperature
range-30°C (-22°F) to 200°C (392°F) 2 X 150 g (5.3 oz)
TILT CAB AND TRACK TENSION PUMP
ATF oil : Dexron III, Dexron II, Type F, Type A Suffix A
Biodegradable oil: Panolin HLP Synth 46, York
Bio 777 VG 46
Operating and Maintenance Manual
Snow groomer BISON
160
(255)
11 - Maintenance
BISON 908930245 - 30367
11.7
