Prinoth BISON X - Technical Data AUTOMATIC Winch

Technical data AUTOMATIC winch
Figure 138: Dimensions BISON with AUTOMATIC winch
BISON with AUTOMATIC winch
■ Dimensions
A Max. snow groomer height AUTOMATIC winch 3554 mm (140 in)
B Max. vehicle height with winch arm tilted down 3048 mm (120 in)
■ Weight
Dead weight with AUTOMATIC winch 9203 kg (20248 lb)
■ Cable
Diameter 11 mm (0.43 in)
Minimum breaking strength of cable 116 kN (26080 lbf)
Max. cable length 1200 m (3940 ft)
■ Operating data
Max. frontal climbing ability* 100 %
Max. lateral stability* 45 °
Max. cable traction force 45 kN (10116 lbf)
Snow groomer speed with AUTOMATIC winch fitted during winch
operation
0 km/h (0 mph)...17 km/
h (11 mph)
Turning radius (snow groomer turns on own axis) 0 °
* on snow
Operating and Maintenance Manual
Snow groomer BISON
248
(255)
15 - AUTOMATIC Winch
BISON 908930245 - 30367
15.9
