1. Release the lever (4) at the back of the
bracket.
2. Swivel the steering console to the left or right until the desired position is reached.
3. Tighten the lever (4).
Folding up the steering console
■ Lift the steering console until it is folded vertically upwards.
Control console
Figure 14: Control console
Pos. Name Description
1 A33 Display
➽
See "Display description" (p. 75)
Operating and Maintenance Manual
Snow groomer BISON
52 (255)
5 - Vehicle
BISON 908930245 - 30367
■
5.9
