Cabin roof
Figure 11: Equipment and controls located at the cabin roof
Pos. Name Description
1 Interior lamps
2 Coat hook (2x)
3 Speaker (2x)
4 Adjusting lever for the spotlight
➽
See "Using the spotlight" (p. 50)
5 Rear-view mirror
6 Sun visors
7 Closing lever of the glass sunroof
➽
See "Open and close the glass sunroof" (p. 49)
Open and close the glass sunroof
CAUTION
Risk of injury
►
Do not lean out of the sunroof during operation of the vehicle.
■ Open the sunroof
Pull
the handle (1) until it snaps open and
then push it until the glass is lifted up to its
maximum opening angle.
■ Close the sunroof
Pull the handle (1) until the glass is completely closed and the handle snaps into place.
The glass sunroof can be detached in order to be able to use it as an emergency exit. However, this
possibility must only be used in emergency situations.
Snow groomer BISON
Operating and Maintenance Manual
BISON 908930245 - 30367
5 - Vehicle
49 (255)
