Pos. Name Description
11 Constant up/down
pressure potenti-
ometer
Use this potentiometer to control the up/down pressure once the "Up/
down
pressure charge" button has been activated on the joystick.
➽
See
"Joystick" (p. 60)
12 R34 Rotary switch:
Engine speed po-
tentiometer
By turning the rotary switch the idle speed of the engine can be set man-
ually.
This
allows the driver to determine the desired engine speed and select
the speed as well as the steering via the steering lever.
■ Turn the engine speed potentiometer clockwise = increase speed
(up to MAX)
■ Turn the engine speed potentiometer counter-clockwise = reduce
speed (down to MIN)
The function is available for forward, neutral and reverse travel.
➽
See "Driving with the engine speed potentiometer" (p. 118)
13 R12 Rotary switch: Rear tiller shaft speed setting
14 Rotary rocker
switch: Outside
mirror adjusment
➽
See "Adjusting the outside mirror" (p. 64)
15 B118 Rotary push-
button switch:
Menu navigation
➽
See "Navigating in the menu" (p. 76)
With the rotary push-button you can also:
Activate and deactivate the rear view camera manually
■
Press for 2 s = rear view camera ON
■ Press for 2 s again = rear view camera OFF
Activate and deactivate the defrost function
■ Push forward once = defrost function ON
■ Push forward again = defrost function OFF
➽
See "Activating the defrost function" (p. 66)
Control the driver's cab heating and ventilation
Adjust the display backlight
■ Turn the push-button clockwise = increase backlight
■ Turn the push-button counterclockwise = decrease backlight
16 S29 Push-button
switch: Emergency
OFF switch for
emergency stop
To park the vehicle and for emergency braking, press the red Emergency
OFF
switch. This activates the parking brake and switches off the snow
groomer standby and operational readiness of the attachments. The
Emergency OFF switch is released by turning clockwise.
17 Rocker switch: Cabin lighting
18 Storage compartment
NOTICE
Risk of battery discharge
►
When the engine is switched off, switch off the interior lighting of the driver's cabin, otherwise
battery discharge will occur.
Operating and Maintenance Manual
Snow groomer BISON
54 (255)
5 - Vehicle
BISON 908930245 - 30367
