Figure 21: Fuses and relays under the right passenger seat
Pos. Name
1 Relays
2 Fuses (5 to 20 A)
3 Fuses (40 to 60 A)
Figure 22: Schematic on the inside of the electrical box cover under the right passenger seat
Fuses under the right passenger seat
F3 Side window heating 50 A
