Pos. Tension/loosen the tracks (C.10) Pos. Automatic brake operation (C.15)
1 Tension tracks left side 1 Steering lever (FNR) sensitivity (25–75%)
2 Tension tracks both sides 2 Accelerator pedal sensitivity (25–75%)
3 Tension tracks right side 3 Steering lever (FNR) set steering reserve
(0%-10%)
4 Loosen tracks left side 4 Automatic brake - reaction time
5 Loosen tracks both sides
6 Loosen tracks right side
The track tension is only working when the
operational
readiness switch for the attach-
ments is active, otherwise the symbol will
be shown in the page here (7).
Figure 51: Driver's cab operation (C.20) II Rear tiller operation (C.30)
Pos. Driver's cab operation (C.20) Pos. Rear tiller operation (C.30)
1 Windscreen wiper(s) interval duration 1 Rear attachment selection
■
Rear tiller
■
Board
■
No attachment
2 Windscreen wiper heater ON / OFF 2 Automatic lowering of rear tiller when trav-
elling forward ON / OFF - tiller ON
3 Front windscreen / rear window heating ON
duration (min)
3 Automatic raising of rear tiller when revers-
ing ON / OFF - tiller OFF
4 Front windscreen / rear window heating
OFF duration (min)
4 Automatically raising of rear tiller side wings
ON / OFF
5 Side window heating ON duration (min) 5 Automatically raising of rear tiller side wings
ON / OFF
6 Side window heating OFF duration (min) 6 Tiller motion (speed) ON when raised. (Re-
verts to OFF on restarting the vehicle.)
Operating and Maintenance Manual
Snow groomer BISON
94 (255)
6 - Display
BISON 908930245 - 30367
