-83-
18. Tilt the top of the printhead cartridge toward the back of the printer, about 20º.
19. Gently seat the back of the printhead cartridge into the print engine.
20. When the back of the printhead is firmly seated, gently rotate the printhead
cartridge into position against the stops on the printhead connector board until it
clicks into place.
21. Slowly close the printhead latch. The fluidic couplings will advance and seal to the
printhead cartridge.
22. Close the printhead latch. When the printhead latch is closed, the printer will
prime, clean and cap the printhead automatically. This operation will generally
take a minute or two, and will be apparent from sounds emanating from the print
engine. If the engine doesn’t start it automaticaly, then open the Toolbox and
press the system prime.
23. When the system is primed, print a test printjob from Toolbox to make sure the
cleaning process was right and the printhead is working properly.
Waste Ink Absorber Replacement
The waste ink absorber was designed to last the life of the printer under normal printing
conditions, taking into account evaporation. Replace the waste ink absorber when ink is
leaking out of the waste ink tray.
1. Use fingers to squeeze the waste ink tray latches inwards, at the front of the unit, to
release and slide the tray out.
