Printing Innovation iCUBE 1 User Manual

-25-
• Black (K) – two cartridges – inserted in the bottom left and bottom right slots.
• Yellow (Y), inserted in the top middle slot.
• Magenta (M), inserted in the top right slot.
WARNING: The ink in the ink tanks may be harmful if swallowed. Keep new and used tanks out
of reach from children. Discard empty tanks immediately.
3.5.3. Installing the printhead
The printhead is the core of the print engine. As sensitive electromechanical
equipment, it requires careful and special handling to avoid damage and ensure
quality printing. NOTE: The printhead is sensitive to electro-static discharge (ESD). Use
ESD protection when handling the printhead.
Priming the printhead
Before the printhead can be used, it must be primed. Priming helps purge both the
liquid and air in the ink lines to allow reliable printing. Priming can also help to remove
To make sure you have a good contact, remove the ink tank and reinsert twice
Picture of inserting the ink cartridges
Cyan
)
C
(
, inserted in the top left slot.
Black
Black
Magenta
Yellow
Cyan
