Print Specifications
Print Specifications
Printhead resolution
(dots per inch/mm)
203 dots/inch (8 dots/mm)
Printing method Direct thermal
Dot size 0.125 x 0.125 mm
(width x length) (1 mm = 8 dots)
Print speed Max. 4 ips (100 mm/sec)
(inches per second) 2,3 ips for Peel-Off mode
Max. print width 4.09” (104 mm)
Max. print length 90” (2286 mm)
Printout bias
Vertical: 1 mm max.
Horizontal: 1 mm max.


Media Specifications

Media Specifications
Media roll capacity Max. 2.65” (67.3 mm) OD
Media core diameter 0.5 ~ 1” (12.7 mm ~ 25.4 mm) ID core
Media type
Continuous, die-cut, gap/black mark, External fan- fold,
receipt
Media wound type Outside wound
Media width 2” ~ 4.41” (50.8 mm ~ 112 mm)
Media thickness
0.0022”~0.0065” (0.055 mm ~ 0.165 mm)
0.5in Hub = 2in to 4.41in (50.8mm to 112mm)
1
0.75in Hub = 2in to 4.34in (50.8mm to 110.3mm)
1.00in Hub = 2in to 4.34in (50.8mm to 110.3mm)
Label length 0.500”~90” (12.7 mm ~ 2286 mm)
Label length (peel mode) 1” ~ 6” (25.4 ~ 152.4 mm)
External fan-fold media
Stack height: 2.75” (70 mm)
Page length: 6” ~ 12” (152 mm ~ 305 mm)
Black Mark Min. 0.3150” (8 mm) (W) x 0.0785” (2 mm) (H)
Gap height Min. 0.0785” (2 mm)

Note:
1. 0.5in Hub is located under 0.75 to 1.00in Hub adapters. Remove Phillips head screw and
nut from each Media Holder
