OPERATION
Page 60 of 99 USER MANUAL PSPC UM-PSPC-06-E/10-2012
SERVICE MENU SEVERAL FUNCTIONS
From the service menu, 8-sub menus are available:
- Adjust transfer mechanism.
- Egg belt control set timers.
- Set repetition denester.
- Set stacker height.
- Check encoder position.
- Vacuum stand-by.
- Sensor control.
- Back to factory settings.
Check encoder position:
The encoder keeps track of the position of the transfer lever with vacuum head. Here the current
encoder position is displayed. The encoder has a zero position, which is the vertical position of the
transfer lever. If an “F” is shown before the number the encoder position is negative which means that
the transfer lever is positioned towards the cup conveyor. Without an “F” before the number, the
encoder position is positive which means that the transfer lever is positioned towards the output
conveyor.
Vacuum stand-by:
When Vacuum ON is selected, the vacuum pump is running as long as the main switch is ON.
When Vacuum stand-by is selected, the vacuum pump starts running when the system is started and
stops when the system is stopped unless the transfer arm is not in its rest position. Toggle F4 to select
vacuum ON or vacuum stand-by.
Back to factory settings:
Using this menu resets the following parameters back to the factory settings:
- Sensor control (all sensors selected).
- Stack height (6 trays).
- Denester repetition (3 times).
- Auto feed egg belt (OFF).
- Egg belt control start delay (1.5 seconds).
- Egg belt control stop delay (1.5 seconds).
