TPW MODBUS © SENNET CONTROL GmbH Page 8 of 11
Main alarm active?
• 0x00: not active
• 0x01: active low
• 0x02: active high
10267-10272 : 6 registers reserved (12 bytes)
… up to 32 alarm channels, each mapped into an area of 32 registers (64 bytes)
to register 11265 which is the last register allocated to the alarm section.
Section 5: Analog Output – NOT IMPLEMENTED
Operation Mode,
• 0x00 = Voltage output mode 0…10 [V]
• 0x01 = Current output mode 0…24
[mA]
Analog Output #0
(DAC ID)
UMC ID – index of the UMC to be outputted
on the DAC,
0xFF = means this DAC is unused
% of total range low value,
X1 value for calculating offset and gain
UMC low value,
Y1 value for calculating offset and gain
% of total range high value,
X2 value for calculating offset and gain
UMC high value,
Y2 value for calculating offset and gain
% of total range low extended,
defines to what level the output of values
can drop
% of total range high extended,
defines to what level the output of values
can rise
% of total range alarm low level,
defines level for under-range
% of total range alarm high level,
defines level for over-range, and UMC
errors
11284 – 11296 : 12 registers reserved (24 bytes)
… up to 32 analog output channels, each mapped into an area of 30 registers (60 bytes).
to register 12225 which is the last register allocated to the analog output section
Section 6: Loggers config
Data Logger - Cycle type
0x00 = Fixed period
0x01 = Each N UMC measurement cycles
Data Logger - Cycle Period
Data Logger - Start time (Unix timestamp)
Data Logger - End time (Unix timestamp)
Event Logger - Minimum log level
• 0x00 = Info
• 0x01 = Warn
• 0x02 = Error
• 0x03 = Critical
12233 – 12300 : 67 registers reserved (134 bytes)
