PRO AIR TPK 21 - Touchscreen Calibration

8.9 Touchscreen Calibration
44
This menu item is used to calibrate the touchscreens. Calibration should be performed if the
screen responds inaccurately when touched.
To calibrate the touchscreen, proceed as follows:
1. Select one of the three segment fields (the background turns dark and control keys appear
at the bottom of the display).
2. Select „Settings“
The following display appears:
PIN
- - - - - -
1
2
3
4
5
6
7
8
9
0
X
3. Enter your personal PIN code (if it has already been changed). If the device is
still in its factory settings, key in 111111.
1
2
3
Class
ISO 8573-1
1.17
bar
Dew-/Frostpoint
- 7.0
o
C
4
Pressure
