„Source“ allows you to set the parameter that you wish to monitor using Alarm 1.

You may choose between following channels:

Geräteeinstellung

Filter

Einheit

Datum / Uhrzeit

Geräteeinstellung

Filter

Einheit

Datum / Uhrzeit

None

System Pressure

A Pressure

Temperature

None

System Pressure

Ambient Pressure

Temperature

Rel. Humidity

Dew-/Frostpoint

ppm Volume

Absolute Humidity

Pre-alarm 1

Alarm 1

Pre-alarm 2

Alarm 2

Select the „Source“ field (the field will be highlighted) and go to the desired value in the list that

appears (using the scroll function or if necessary).

Confirm your choice with .
