© 2015 Proceq SA 3
Contents
1. Safety and Liability ....................................................................5
1.1 Safety and Usage Precautions .............................................................. 5
1.2 Liability ................................................................................................... 5
1.3 Safety Instructions ................................................................................. 5
1.4 Designated Use ..................................................................................... 5
1.5 Labeling used in the Manual .................................................................. 5
2. Overview of the Profoscope .......................................................6
3. Tutorial ....................................................................................... 7
3.1 The Measurement Principle ................................................................... 7
3.2 Calibrated Measuring with Profoscope ................................................. 7
3.3 The Measuring Range ............................................................................ 8
3.4 Factors
Affecting
the
Measur
ement .............................................8
4. Getting Started ...........................................................................11
5. Performing a Real Test ...............................................................12
5.1 Preparations .......................................................................................... 12
5.2 Locate a Rebar ...................................................................................... 13
5.3 Measure Cover Depth ............................................................................ 18
5.4 Measure Rebar Diameter ....................................................................... 22
6. Settings ......................................................................................24
6.1 Navigating through the Settings Menu .................................................. 24
6.2 Regional
Setting ............................................................................25
6.3 Rebar
Diameter ...........................................................................25
6.4 Measuring
Range
Selection .........................................................26
6.5 Audio
Setting ................................................................................26
6.6 Minimum
Cover ..............................................................................26
6.7 Neighboring
Bar
Compensation ....................................................27
6.8 Memory Function (for Profoscope+ only) .............................................. 27
7. Technical Specifications ............................................................29
