6.7 Neighboring
Bar
Compensation
Cover and bar diameter measurements are influenced by neighboring bars. This can be com-
pensated by selecting the bar spacing.
Metric, ASTM mm,
Japanese
ASTM
inch
- mm - inch
50 mm 2.0 inch
60 mm 2.4 inch
70 mm 2.8 inch
80 mm 3.2 inch
90 mm 3.6 inch
100 mm 4.0 inch
110 mm 4.4 inch
120 mm 4.8 inch
130 mm 5.2 inch
Tab. 4 Spacings for neighbor bar corrections
The space setting is possible with a spacing from 50 mm to 130 mm / 2.0” to 5.2”.
For larger spacing the compensation is not necessary and the space value must be set to zero (-).
6.8 Memory Function (for Profoscope+ only)
Fig 32: Main menu icons of Profoscope+
Select memory card symbol to activate the data storage mode. Minimum cover function is auto-
matically deactivated if the memory function is turned on.
Two different memory functions are supported:
Fig 33: Sub menu “Memory”
After selecting the memory function, the status line on the measuring screen is modified:
