3.0 Basic parameters and requirements
The MyPlasm CNC control system is
managed via USB 2.0 via the Windows control
software, which can be downloaded for free from
the manufacturer's website:
proma-elektronika.com → "download".
The software has a freeware licence which does
not exclude use for commercial purposes.
The control software works correctly on
Windows XP, 7, 8, 10, 11. The additional
modules MyMiniCAD and 3D Viewer require at
leastWindows 7. The software has very low
requirements and works with any PC / Laptop
hardware configuration.
Power supply for the controller: 24V DC ( 22 - 26V DC)
Maximum current consumption : 0.6A ( 600mA )
Number of axes : 4
Motor driver output signals : TTL 5V STEP (PUL) / DIR 40mA
Motor frequency: 0.02 - 250kHz
Limit sensor inputs ( 8 x 24V ) : NPN NO, NPN NC, Contacts,
active state : LOW
Dimensions of CNC Controller : 120 x 100 x 15 [mm].
Dimensions of the Plasma Interface: 115 x 60 x 25 [mm].
Measuring voltage ARC / THC max : 300V DC ( test 1000V DC )
HF / HV protection : 10kV AC ( 15kV AC test )
Optical isolation : 2 x 3kV
PC communication : USB
Plasma Interface Communication : RS485
Optional outputs ( 2 ) : OC 0.5A 5-30V
