User Manual
PROTEC GmbH & Co. KG, In den Dorfwiesen 14, 71720 Oberstenfeld, Germany
keep the machine in working condition during the stand-by mode, the electronics have been furnished
with two specialities: The anticrystallisation Function and the Time Replenishment.
5.2.3 Anti-crystallization function
During the stand-by mode, the film transport, the dryer ventilation, the dryer heating and the water
inflow are activated every 20 minutes for a period of 20 seconds. This prevents the build-up of crystals
on the rollers.
5.2.4 Time replenishment (Anti-oxidation function, Flood replenishment)
Also during the stand-by, the developer chemicals are subject to change which causes their
deterioration. By means of the time replenishment, a replenishment cycle is activated after 60 minutes
without replenishment. With this function, the quality of the developer chemicals are maintained even
when standing idle for long periods. The time replenishment function can be deactivated.
5.2.4.1 Setting off the time replenishment
1 Switch the unit off.
2 Press the buttons processing time (4) and replenishment time (7) simultaneously and keep
pressed.
3 Switch the machine on again and release the pressed buttons
4 Switch the time replenishment on or off with cursor keys (2 and 3). If you enter „0“ , time
replenishment is off, „1“ switch it on
5 Switch the unit off to save the settings
5.2.5 Working parameters
The processing machine develops, fixes, rinses and dries the film materials automatically. The film and
chemical requirements can be adjusted accordingly and stored in the control unit.
5.2.5.1
Display working parameters
1 Switch processor on
2 Press the respective mode button (4-7) and kept it pressed to display the set value
Press the respective mode button (4-7) and let it go to display the current actual value.
5.2.5.2 Setting working parameters
1 Switch processor on
2 Machine must be in the stand-by mode and no film must be in the processor
3 Press the respective mode button (4-7) and keep pressed: The display shows the set working
parameter
4 Change the value by means of the arrow button (2 and 3) until required value appears on the
display. The upward arrow button (2) increases and the down arrow button (3) decreases the
value
5
Release the mode button
5.2.6 Processing time
The processing time, is the time, it takes the front end of a film from the infeed of the processor until it
reaches the film exit. The processing time is set by the speed with which the film is transported through
the machine. Depending on the requirements, this time can be varied from to 2.5 minutes (150
seconds) to 10 minutes, adjustable in 0.1 minute-steps (adjusting the processing time: see 5.2.5.2)
Processing and developer time relation
Processing time (min) Developer time (s) Infeed speed (cm/min)
2.5 41 35
3.0 49 28
4.0 66 21
5.0 82 17
6.0 99 14
7.0 115 12
