5.3.2.7 The film does not transport correctly
• Film is fed in and gets caught in the machine: Check the positioning of the racks in the
machine and make sure that the latches are closed.
5.3.2.8 Film cannot be fed, the display shows „E1“
• Close machine cover securely, paying special attention that the switch on the rear of the
control panel is actuated
5.3.2.9 Film is in the infeed and nothing happens
• Display is flashing: Control is in the manual mode. Switch back to Automatic mode
(see 5.2.12.2 ).
• Insert the film into the film feed so it passes the film detection switches. Feed the film to
activate one of the switches. If the unit should not start, activate the other switch. If the
processor still does not start, call your service technician. In the meantime, with limitations the
processor may be operated in the Manual Mode (see 5.2.12.1)
5.3.2.10 Film is caught up in the racks
• Switch machine off and remove cover
• Check in which rack the film is caught up in and remove the respective rack
• If possible, catch hold of the film end by hand and by manually turning the drive-shaft, pull the
film out of the rack
• If a film is caught up in the machine due to a power cut, it can be transported out of the
machine by activating the transport with a film in the infeed (machine can also be started up in
the manual mode, see “Manual starting and stopping the film transport 5.2.12.3
CAUTION!
Ensure correct seating of roller racks; keep the lock closed at all times.
Don’t operate processor with empty replenishment tanks.
After a long machine shut down check bath level and refill if necessary.
5.4 Error messages
Machine errors are shown on the display as abbreviations. The cause of error is explained below. For
service technician: problem solution see “Trouble shooting” capture 7.
Display Cause and possible correction
E1
Cover switch is not actuated. Place cover correctly on the machine and
ensure that the cover switch behind the control panel is actuated. If the
error cannot be corrected, then the cover switch may be broken.
UU
Too low level of the developer bath. Check
the level and fill up by
pumping manually or refilling manually
