Pulsar ACCOLADE 2 LRF User Manual

Notes:
To select a rangefinding reticle, please go to the respective menu option.
To select a unit of measurement (meters or yards) go to Units of Measure subsection of
the General Settings section.
Additional Information:
Accuracy of measurement and maximum range depend on the reflection ratio of the
target surface, the angle at which the emitting beam falls on the target surface and
environmental conditions. Reflectivity is also affected by surface texture, color, size and
shape of the target. A shiny or brightly colored surface is normally more reflective than a
dark surface.
Measuring range to a small sized target is more difficult than to a large sized target.
Accuracy of measurement can also be affected by light conditions, fog, haze, rain, snow
etc. Ranging performance can degrade in bright conditions or when ranging towards the
sun.
To see the button operation scheme click here.
To see the remote control button operation scheme click here.

Pulsar ACCOLADE 2 LRF Specifications

General

Objective Lens Diameter	50 mm
Detection Range	1800 m
Sensor Resolution	640x480 pixels
Display Type	AMOLED
Pixel Pitch	17 µm
Frame Rate	50 Hz
Laser Rangefinder Range	1000 m
Protection level	IPX7
Dimensions	164x130x64 mm
Waterproof	Yes
Fogproof	Yes
Weight	0.7 kg
Display Resolution	640x480 pixels
Operating Temperature	-25 … +50 °C
Battery Type	Li-Ion Battery Pack
