Pulsar blackbox 130 User Manual

Page 5
Outputs
Analogue output Isolated (floating) or non-isolated output of
4-20 mA or 0-20 mA into 1K

(user
programmable and adjustable) 0.1%
resolution
Serial Port (Digital output) Full Duplex RS232 for programming and
data extraction
Volt free contacts, number and rating 2 form "C" (SPDT) rated at 2A at 115V AC
Display (optional) 2 x 12 alpha numeric
Programming
PC programming (standard) via RS232 using supplied software
Remote programming (optional) via RS232 using optional hand held
calibrator
On board programming (optional) via integral keypad
Programming security via passcode (user selectable and
adjustable)
Programmed data integrity via non-volatile RAM
Supply
Power supply 115 VAC +5% / -10% 50/60 Hz,
dc 10 - 28V
10W maximum power (typically 5W)
Overvoltage Category II
Fuses
Mains (F1) 100 mA T at 115 VAC
DC (Battery) (F2) 1A Thermal (self resetting after power
removed). Not user replaceable
Transducer (F3, F5) Littelfuse 242 series 100mA Part No.
0242.100. This fuse is not user replaceable
and has a 4000A breaking capability to
comply with certification of the Exm version
of dB series transducers.
Remote Communicator
Power Supply Power supplied via blackbox RS232
interface.
Pulsar Process Measurement Limited operates a policy of constant development and
improvement and reserve the right to amend technical details as necessary.
