Page 20
Chapter 3 How To Use Your blackbox Level System
In order to view or change parameter values one of the following methods
must be used:
PC Handheld Programmer (Standard)
Your blackbox 130 comes complete with the PC Handheld Programmer
software, contained on CD. Insert the CD into the CD drive of the PC intended
to be used to carry out the programming of the blackbox and install the
software, following the on-screen instructions. Once the software is installed
connect the computer via its serial port to the blackbox RS232 serial interface
RJ11 connector, located on the terminal connector strip, inside the blackbox
enclosure. Double click the ‘Handheld Programmer’ icon, installed on your
desktop and the PC will automatically connect to the blackbox. Once
connected you will briefly see the message illustrated on the display below
which, after connecting successfully, will then change to display the current
measurement, dependent on mode and measurement unit's chosen. When
using the PC Handheld Programmer software, keypad input can be achieved
by using a ‘mouse’ or similar device to place the cursor over the relevant key
followed by a ‘left’ click, alternatively numeric detail can be entered directly
from the PC keyboard as can ‘ENTER’ and ‘CANCEL’ (Esc. Key).
