Page 4
Product Specification
Physical
Standard Wall Mount Enclosure
Outside dimensions 5.12 x 5.12 x 2.36 inches
(130 x 130 x 60 mm)
Weight Nominal 1.4lbs (0.65 kg)
Cable entry detail underside fitted with 3 x M20, nylon cable
glands
Large Wall Mount Enclosure (optional)
Outside dimensions 5.12 x 7.09 x 3.35 inches
(130 x 180 x 85 mm)
Weight Nominal 1.65lbs (0.75 kg)
Cable entry detail underside fitted with 5 x M20, nylon cable
glands
Enclosure material/description Polycarbonate base with Polycarbonate lid,
flammability rating UL94-5V
Separation
Transducer cable extensions 3 conductor 20AWG screened
Nominal separation 3,280 ft. (1000m). For greater separation
distances please consult Pulsar
Environmental
Mounting Indoor/Outdoor
Relative Humidity (IP Rating) IP66 (NEMA 4X enclosure)
<35
o
C (95
o
F) at 93% relative humidity
Pollution Degree 2
Altitude 2000m maximum
Max. & min. temperature (electronics) -4ºF to 120ºF (-20 ºC to +50 ºC)
Flammable atmosphere approval Safe area: compatible with approved dB
transducers (see transducer spec' sheet)
Approvals
UL Certificate Number E257330
CE approval See EU Declaration of Conformity
Performance
Accuracy 0.25% of the measured range or
0.24" (6 mm) (whichever is greater)
Resolution 0.1% of the measured range or 0.08" (2 mm)
(whichever is greater)
Max. range Dependant on transducer (maximum 131ft
(40m) dB40)
Min. range Dependent upon transducer (minimum 0.41ft
(0.125m) dB 3)
Rate response fully adjustable
Echo Processing
Description DATEM (Digital Adaptive Tracking of Echo
Movement)
