Important Information
Before applying AC power (mains), make sure the supply is 115 VAC
+5% / -10%
Never operate the blackbox with terminal access exposed.
An external switch or circuit breaker should be installed near to the
blackbox to allow the supply to be removed during installation and
maintenance. In addition, the relay contacts should also have a means
of isolating them from the blackbox.
Interconnecting cables must be adequately insulated in accordance
with local regulations. Strip back 30 mm of the outer insulation of the
cable. Strip 5 mm of insulation from the end of each conductor. Twist
all exposed strands of the conductor together. Insert the stripped
conductor into the terminal block as far as it will go and tighten the
terminal block screw. Ensure that all strands are firmly clamped in the
terminal block and that there is no excess bare conductor showing,
and no stray strands.
Important Information
If the equipment is installed or used in a manner not specified in this
manual, then the protection provided by the equipment may be
impaired.
Preparation for Operation
Before switching on, check the following:
✓ The blackbox is mounted correctly and is in a ‘safe’ area.
✓ The power supply is correctly installed.
✓ The relays are connected correctly.
