Test Parameters
Simulation
P980 Simulate
Test mode is used to simulate the application and confirm that all parameters
and relay setpoints have been entered as expected. During simulation, there is
a choice of whether the relays will change state (hard simulation) or not (soft
simulation), but the LED’s will always switch according to how the relays
have been programmed, and the output will change accordingly. If you want
to test the logic of the system that the relays are connected to then select a
hard simulation, but if you don’t want to change the relay state, then select a
soft simulation.
There are two simulation modes, automatic and manual. Automatic
simulation will move the level up and down between empty and full level and
activate the relay and/or corresponding LED at the switch points
programmed, if you wish to change the direction of the level movement at
any time this can be done by using the arrow keys. In manual simulation,
using the arrow keys will allow you to move the level up and down as
required.
