Pulsar blackbox 130 User Manual

Page 47
Parameter Listing
This section describes all of the parameters. Any parameter can be reset to its
default, by pressing the hot key, while in program mode.
Application Parameters
Operation
P100 Mode of Operation
This parameter sets the mode of operation, when in run mode, and can be set
to one of the following:
Option
Description
1 = Distance
(Default)
Display and Output relative to the distance from the
transducer to the surface.
2 = Level
Display and Output relative to how full the vessel is.
3 = Space
Display and Output relative to how empty a vessel is.
When fitted with optional display and integral keypad
5 = Volume
Display and Output relative to volume of material in the
vessel.
P101 Transducer
This parameter should be set to the transducer being used with the unit, and
can be set to one of the following:
Option
Description
1 = dB3
Transducer is a dB3. Range 0.410 to 9.843 feet
2 = dB6 (Default)
Transducer is a dB6. Range 0.984 to 19.685 feet
3= dB10
Transducer is a dB10. Range 0.984 to 32.808 feet
4= dB15
Transducer is a dB15. Range 1.640 to 49.213 feet
5= dB25
Transducer is a dB25. Range 1.969 to 82.021 feet
6 = dB40
Transducer is a dB40. Range 3.937 to 131.234 feet
7 = dBS6
Transducer is a dBS6. Range 0.656 to 19.685 feet
P102 Material
This parameter should be set to the type of material being monitored
Option
Description
1 = Liquid
Use for liquids and flat solids
2 = Solid
Solid material that is heaped at an angle
3 = Closed Tank
Use for applications within a closed vessel or where a
secondary echo response may become focussed to
create a larger echo than the first.
