Pulsar blackbox 130 User Manual

Page 24
Keypad
Hot Keys
There are five hot keys on the keypad, which can be used to quickly access
common parameters for viewing only, while in Run Mode. Pressing the hot
key once will display the first parameter, then repeated pressing will display
subsequent parameters, as available, then the blackbox reverts to Run Mode.
In program mode, they have different functions, the functions are shown
below.
Hot
Key
Run Mode
Program Mode
Not used with blackbox 130.
Not used with blackbox
130.
Displays echo confidence, echo
strength, H.A.L.L., average
noise, peak noise or temperature.
Not used with blackbox
130.
Not used with blackbox 130.
Reset parameter to default
setting.
Instantaneous mA output.
Not used with blackbox
130.
Dependant on application
displays Distance, Level, Space
or Volume (optional) in units of
measurement.
Not used with blackbox
130.
Not used with blackbox 130.
Takes you to the last
parameter edited, when you
first enter program mode.
Gives details of unit type,
software revision and serial
number.
Enter Decimal Point.
