To program the blackbox for this Example, proceed as follows.
Access the Program Mode
Key in the passcode 1997 and press ENTER
Using the menu system access the parameters, as detailed below, and select
the relevant options and ENTER.
Top Level
Menu
Sub Menu
Parameter Detail
Selected Value
Application
Operation
P100 Mode
5 = Volume
P101 Xducer
2 = dB6
Distances
P104 Measnt Units
4 = feet
P105 Empty Level
13.5
P106 Span
11.5
Relays
Relay 1
P210 Relay 1 Type
1 = Alarm
P211 R1Function
1 = Level
P212 R1 ID
2 = High
P213 R1 Set 1
10.0
P214 R1 Set 2
9.0
Relay 2
P220 Relay 1 Type
1 = Alarm
P221 R1Function
1 = Level
P222 R1 ID
4 = Low
P223 R1 Set 1
1.0
P224 R1 Set 2
2.0
Volume
Conversion
P600 Vessel Shape
0 = Cyl.Flat Base
P601 – P603
Vessel Dimensions
Enter dimensions as
required
P604 Calc. Volume
Shows the volume
as calculated by the
blackbox
P605 Volume Units
Select as required
P606 Correction
Factor
Enter value of any
correction factor
e.g. specific gravity
of material
P607 Max. Volume
Displays the Max.
Vol. as calculated
by the blackbox
Programming is now complete and the unit can be returned to the run mode,
press CANCEL until Run Mode? Is displayed on the display press ENTER,
and the blackbox will return to the Run Mode.
