Pulsar blackbox 130 User Manual

Page 56
Alarm ID
Description
Setpoints
6= In bounds
Relay goes “ON” if
value is inside the zone
between the two
setpoints.
Relay Setpoints,
P213, 223 and
P214, 224 can be
set in any order as
the unit ‘knows’
that you are setting
an inbounds alarm.
7= Out of bounds
Relay goes “ON” if
value is outside the zone
between the two
setpoints.
Relay Setpoints
P213, 223 and
P214, 224 can be
set in any order as
the unit ‘knows’
that you are setting
an out of bounds
alarm.
The fourth parameter and the fifth parameter for each relay set the Alarm
“ON” and “OFF” points. For a high alarm the “ON” is set higher than
“OFF”. For low alarm, then “ON” is set lower than “OFF”. See the
appropriate alarm ID, table (P212, 222) for further information.
When P211, P221 = 3 (Loss of Echo) or 4 (Loss of Clock)
This parameter has no function and will not be displayed.
When P211, P221 = 1 (Level) or 2 (Temperature)
P213, P223 - Relay Setpoint 1
Determines the “ON” or “OFF” point for the alarm according to the ID selected.
P214, P224 - Relay Setpoint 2
Determines the “ON” or “OFF” point for the alarm according to the ID selected.
