Page 17
Draw / Inflow
The Pump Inflow and Pump Draw parameters are only used when the unit is set
up to calculate Pump Efficiency (available in Ultra 5 and Zenith units only).
P150 Pump Inflow
This is a read only parameter that displays the calculated inflow rate in m/min.
P151 Pump 1 Initial Draw
This parameter is the calculated initial draw in m/min of a calibrated pump. If
required this value can be entered manually.
P152 Pump 2 Initial Draw
P153 Pump 3 Initial Draw
P154 Pump 4 Initial Draw
P155 Pump 5 Initial Draw
P156 Pump 6 Initial Draw
P157 Pump 7 Initial Draw
P158 Pump 8 Initial Draw
P159 Pump 9 Initial Draw
P160 Pump 10 Initial Draw
