Pulsar Zenith 140 User Manual

PULSAR MEASUREMENT
13
DIGITAL INPUTS
Digital Inputs
Min. Input Voltage 4.5VDC. Max. Input Voltage
30VDC (Max Current 3mA). 24VDC Input Supply
maximum total current 24mA.
PROGRAMMING
On-board programming
By integral keypad
PC programming
Via RS232
Programming security
Via passcode (user selectable and adjustable)
Programmed data integrity
Via non-volatile RAM, plus backup
SUPPLY
Power Supply
115V AC + 5% / -10% 50/60 Hz,
230V AC + 5% / -10% 50/60 Hz,
DC 18 - 36V
Fuses
10W maximum power (typically 6W)
100 mA at 170-240 VAC (fitted as standard to wall
units).
200 mA at 85-120 VAC (fitted as standard to fascia
units).
Pulsar Measurement operates a policy of constant development and
improvement and reserve the right to amend technical details, as necessary.
