Pulsar Zenith 140 - Page 43

PULSAR MEASUREMENT
43
APPLICATION
NO. OF
PUMPS
PUMP NUMBER
ON
SETPOINT
OFF
SETPOINT
Pump Up
One
Pump 1
50%
80%
Pump Up
Two
Pump 1
Pump 2
50%
30%
80%
80%
Pump Up
Three
Pump 1
Pump 2
Pump 3
50%
40%
30%
80%
20%
80%
Pump Up
Four
Pump 1
Pump 2
Pump 3
Pump 4
60%
50%
40%
30%
80%
80%
80%
80%
Pump Up
Five
Pump 1
Pump 2
Pump 3
Pump 4
Pump 5
60%
50%
40%
30%
25%
80%
80%
80%
80%
80%
Pump Up
Six
Pump 1
Pump 2
Pump 3
Pump 4
Pump 5
Pump 6
60%
50%
40%
30%
25%
20%
80%
80%
80%
80%
80%
80%
RELAY
FUNCTION
RELAY ID
ON
SETPOINT
OFF
SETPOINT
Alarm
HiHi
90%
85%
Alarm
High
85%
80%
Alarm
Low
10%
15%
Alarm
LoLo
5%
10%
