Enforcer: Programming Manual
Page: 4
2. General Information
2.1 Default Codes
User: ‘Blank’ Master Manager: 2222 Engineers: 1111
2.2 Initial Power Up
Power up the Enforcer system, an alarm will be generated. Proceed to the Enforcer keypad, which will
display (from power up):
1. Once power has been applied to the Enforcer,
'Please Wait' will be displayed, followed by '485
Comms Lost'. After approximately one minute, the
Enforcer will the time on the display, indicating the
system is ready to use.
2. The Enforcer is defaulted to keypad address '0'.
2.3 Testing The Keypad
With the system unset, press the key for 5 seconds at any keypad. This will cause all the LEDs on
that keypad to illuminate, and the LCD screen to display each pixel. The keypad will revert to normal
display after the test which will last about 10 seconds.
2.4 Wired Keypads/Readers
The Enforcer Keypad and Additional Keypads (EUR0-LCDPZ)
3 additional wired keypads may also be connected to the Enforcer. Refer to the ‘Installation
Manual’ for all connections.
KEY FUNCTIONS:
a = Exit Engineer and Manager menu / Selects Area A.
b = Moves backwards to the previous menu item / Selects Area B.
c = Enables chime and displays additional information in the log / Scrolls back ‘one’ in a sub
menu / Selects Area C.
D = Moves forward in the log / scrolls between options and enters the master manager menu
/Selects Area D.
f p = Not used. [] = Directional buttons.
I = Selects items and enters menus.
A = Cancels items, resets the panel and moves to next item in a menu item.
NOTE 1: If any additional keypads are installed on the Enforcer, it is possible to access the
Engineer Menu on any keypad. For example, if the Engineer menu is accessed on keypad address
0, the other keypads will display ‘System Busy’. To access the Engineer menu on any other
keypad, press the key on the relevant keypad and the Engineer menu will be displayed.
NOTE 2: A Wireless Keypad can be connected to set/unset (LEDRKP-WE)
