Enforcer: Programming Manual
Page: 35
Appendix B. Input Types
Number & Type Operation
00 Unused Factory default. Input is programmed out of operation.
01 Fire
Active at all times. Audible response: Full (differentiated).
Communicator: ‘Fire’ signal.
02 Gas
Active at all times. Audible Response: Full (differentiated)
Communicator: ‘Gas’ signal.
03 HU
#
Active at all times. Audible Response: Full (differentiated)
Communicator: ‘Hold Up’ and ‘Input HU’ signals.
04 Silent HU
#
Active at all times. Audible Response: None
Communicator: ‘Hold Up’ and ‘Input HU’ signals.
05 Tamper
When unset: Audible Response: Internal only Communicator: ‘Tamper’ signal.
When set: Audible Response: Full (differentiated) Communicator: ‘Tamper’ and
‘Unconfirmed’ signals.
06 Intruder
Active when set. Audible Response: Full
Communicator: ‘Intruder’ and ‘Unconfirmed’ signals.
07
Final Exit
(FX)
#
Active when set – initiates entry timer if system not unset before entry time
expires: Audible Response: Full.
Communicator: ‘Intruder’ and ‘Unconfirmed’ signals.
08
Entry Route
(ER)
Active when set, except during entry time.
Audible Response: Full.
Communicator: ‘Intruder’ and ‘Unconfirmed’ signals.
09
ER
(Part FX)
When fully set (A), acts as Entry route input, as above. When part set (B,C,D),
acts as Final Exit input, as above.
10
FX
(Part ER)
When fully set (A), acts as Final Exit input, as above. When part set (B,C,D), acts
as Entry route input, as above.
11 PTS
Active during exit time to complete Setting procedure
No audible or communicator response.
Note: May be used to act as ‘doorbell’ by use of ‘chime’ attribute.
13 Day Alarm
When armed: Audible Response: Full; Communicator: ‘Instant’ signals. When
disarmed: Audible Response: Programmable; Communicator: ‘24hr Alarm’ signal
(if programmed in Alarm Responses menu).
16 Fault
When armed: Audible Response: Full; Communicator: ‘Instant’ signals. When
disarmed: Audible Response: Programmable; Communicator: ‘24hr Alarm’ signal
(if programmed in Alarm Responses menu).
20
Keyswitch
Latched
*
Accepts input from keyswitch (or equivalent) to Set/Unset the Set modes assigned
to it. Setting includes normal exit time, etc. Requires latching action switch.
21
Entry Shock
Input
Active when system set. Works in conjunction with EE input type for detection of
forced entry. See page 35 for details.
23
Keyswitch
Pulsed
*
Accepts input from keyswitch (or equivalent) to Set/Unset the Set modes assigned
to it. Requires momentary action switch to toggle set/unset state.
32 Flood
This input type will work as a 24hr input, any inputs that are programmed for
Flood will activate the external siren.
42 Medical
This input type will work as a 24hr input, any inputs that are programmed for
Medical will activate the external siren.
44
ATE Line
Fail
Once a ATE line fail has been recognised the input will open.
*The use of these inputs will make the system unable to comply with EN50131-1 Grade 2
#
These input types cannot be bypassed.
Entry Shock Input Type (21)
This input type is designed specifically for use with systems installed using BS8243 option 6.4.5.
This input type is always used in conjunction with an Entry/Exit input. The Entry/Exit input is a door
contact on the initial entry door, and the Entry Shock input is a non-latching shock sensor fitted to
the door frame in the vicinity of the lock. If the initial entry door is subjected to gross attack and
forced open, then at the expiry of entry time only one further intruder input need to be activated to
signal a sequentially confirmed alarm – the Entry Shock input counts as the first to alarm. The
Entry/Exit door contact must be opened with 10 seconds of the shock detector triggering for the
Entry Shock response to apply. Triggering the Entry Shock input in isolation will NOT generate an
alarm of any kind.
