91
3. Load t ray back int o drive bay.
i. I nsert t he drive tray into t he NAS. Ver if y that t he tray is correctly orient ed ( t op of
HDD facing right) and fully pushed in.
ii. Close t he lat ch, and lock the switch.
7 .1 .5 . TS- 1 1 2 P, TS- 2 1 2 P and TS- 2 5 1 C
1. Loosen t he screws on t he rear ( t op and bott om ) of t he NAS. Rem ove t he case cover of
the NAS by sliding it apart ( see t he underside of the NAS for visual indicat ors of the NAS
case being locked/ unlocked.)
