We recommend ying in Mode 2 (throttle on left stick), which is the most common
conguration used when ying FPV Drones. Figure 8 details our recommended mix
mapping.
TBS Tango Configuration
If using a TBS Tango, the channel mix output is predetermined for you. Set up your
model for Cleanight in the Tango’s menu.
the QQ190™ is congured with the inputs as AETR1234. This means that ailerons are
set to channel 1, elevator to channel 2, throttle to channel 3, rudder to channel 4, and
Aux in to channel 5-8
• Aux 1 is arm
• Aux 2 is unused
• Aux 3 is ight mode selection
• Aux 4 is buzzer.!
