TBS Crossfire Micro Receiver Installation & Binding
The QQ190™ is made to easily interface with the advanced TBS Crossre Radio system.
We recommend installing a TBS Crossre micro receiver for best results.
To install the Crossre Micro to the QQ190™:
1. Install the BST wire provided with the Crossre micro receiver to the Black Sheep
Telemetry Port on the bottom right of the Electronics stack (gure 1)
2. Install the signal wire included with the Micro receiver to the Colibri Receiver port
(g. 2)
3. Bind the crossre by turning on the radio and crossre transmitter unit, then by
plugging in a battery to the QQ190™. (make sure props are removed)
4. Hold down the button on the crossre transmitter module to enter the Tx menu.
Go to binding, and select “bind”.
5. Push the bind button on the TBS Crossre micro receiver.
6. The Crossre transmitter should now bind to the Crossre receiver.
It is important to make sure to follow the prompts on the transmitter unit to
update the rmware if necessary.
7. Make sure that the Crossre micro is congured for SBUS output. You can do so by
holding the button down on the back of the Crossre transmitter, selecting
Crossre micro, and setting the output to SBUS.
Initial Setup
We have engineered the QQ190™ to be congurable via the OSD with the radio
transmitter sticks. This means that there is no computer connection required to setup
the QQ190™ for ight, however you will need an FPV receiving device such as a set of
goggles or a monitor to perform the initial setup.
We recommend that you use a 5.8ghz receiver setup such as a TBS Tango Radio, or a
pair of Fatshark goggles, or a 5.8ghz FPV monitor to continue with setup.
