Flight Controller Submenu
• PID - Detailed Proportional–Integral–Derivative controller values for Roll, Pitch
and Yaw- This is where you can tune your quad without having to connect a
computer.
• Rate - Stick sensitivity multiplier values- Adjust these values to slow down or
speed up the rate of spin of the QQ190™.
• Settings - Looptime and Idle Motors settings can be adjusted here.
• Calibration -
•
RC/Radio Calibration wizard for setting up the receiver
•
Accelerometer calibration - initiate when QQ190™ is on a leveled surface.
FPV Camera Submenu
• Camera Audio- Enable camera audio transmission if your camera is equipped
with a microphone.
Switch Setting Submenu
• Camera Switch- Disable/Enable- Enable a switch to switch between the 2
camera ports on the FPVision board if 2 cameras are installed on the QQ190™.
• Buzzer Find Sw.- Disable/Enable- Enable a switch activated buzzer if buzzer is
equipped.
Video Transmitter Submenu
• VTX Unlock - Brings you directly to Callsign menu to change the id from the
default “TBS”
• Band - A/B/Race/E/Airwave/User - Video transmitter frequency band
• Channel - 1 to 8 - Channel number (frequency) within the selected band
• Power Level - 25/200/500/800mW - Transmitter output power level
• PIT Mode- Enable pit mode for use during races to test your QQ190™ without
disturbing other pilots using Pit mode frequency and low power. (only receivers
such as the TBS Tango have the ability to receive the pit mode frequency)
• VTX LED Strip - Disable/Enable - Changes LED color depending on the band
used
