Spektrum Receiver Installation
If you are a Spektrum user, you will have to install the Spektrum receiver wire
that is supplied with your QQ190™ to the receiver port. The QQ190™ is
designed in such a way that you will need to partially disassemble the drone to
install the wire. We recommend that you gain easy access to the receiver port
by rotating the LED diffuser housing out of the way. You can accomplish this by
removing the allen screw from the rear right standoff and rotating the housing
to gain easy access to the receiver plug on the Colibri ight controller. The
other, easier option is to remove the Colibri ight controller from the top of the
Powercube stack if you have access to the TBS nut driver (Available at
QuadQuestions.com.)
The TBS nut driver is made specically so that you don't damage the
Electronics stack when removing boards and is the only recommended
tool for servicing the onboard electronics.
For instructions on how to bind and setup your Spektrum radio, please refer to
the manufacturer’s documentation.
Frsky X4R-SB install & binding procedure.
If you are using the recommended Frsky Taranis or TBS Tango radio with an X4R-SB
receiver, then you can bind the radio to the receiver by performing the following
actions:
