Quantech
106
Form QTC3-NM1
Issue date: 12/19/2023
Section 5: Technical data
Weight distribution and isolator
mounting positions
General
Weights of specific chiller models vary significantly as
options are added. As a result, total weights, weights at
individual isolator positions, and actual isolator selec-
tion at each position cannot be published due to the
vast number of possible combinations. This informa-
tion will be available when the specific chiller/ option
selection is made from the local Quantech sales office.
Be aware, weights will change with each option along
with possible isolator changes. Weights and isolators
may need to be recalculated when the option selections
are changed.
Whenever the isolator option is ordered, the isolators
will be shipped loose with the chiller. Packed with
the isolators and also in the control panel informa-
tion packet is a drawing and table specifically for each
chiller, based on the option selection. The drawing and
table will be similar to the two samples shown below
and on the following page. The drawing will show the
isolator locations along with the weight in pounds and
kilograms at the specific location, isolator position,
and location measurements for each isolator.
Sample isolator location drawings
See Figure 36 below for sample printouts supplied in
the isolator package and in the chiller panel literature
packets.
Location
X Distance
in. (mm)
Y Distance
in. (mm)
Vendor Number
Operating Weight
lb (kg)
R1 19.5 (495.3) 1.36 (34.5) ND-D / Yellow 1092 (495.3)
L1 19.5 (495.3) 86.86 (2206.2) ND-D / Yellow 1406 (637.8)
R2 96.1 (2440.9) 1.36 (34.5) ND-D / Yellow 1015 (460.4)
L2 96.1 (2440.9) 86.86 (2206.2) ND-D / Yellow 1304 (591.5)
Unit Shipping Weight
(Display on unit data
nameplate)
kg lb
2032 4480
0
Control Panel
0
R1 R2
L1 L2
X
Y
Top View
Figure 36: Sample Printout Supplied in the Isolator Package and in the Chiller Panel Literature Packet
