Section 5: Technical data
Form QTC3-NM1
Issue date: 12/19/2023
55
Table 11: Electrical data without pumps, R-410A
QTC3 V Hz MCA Min. N/F
disc SW
Min. dual
elem. fuse
and CB
Max. dual
elem. CB
System 1
Compr. 1 Compr. 2 Compr. 3 Std. ow fans
RLA LRA RLA LRA RLA LRA Qty. FLA LRA
3040T
208 60 172 250 200 200 33.3 239 33.3 239
— —
2 7.6 44
230 60 171 250 200 200 33.3 239 33.3 239 — — 2 7.4 37
380 60 119 150 125 125 23.7 145 23.7 145 — — 2 4.5 23.1
460 60 92 150 100 100 17.9 125 17.9 125 — — 2 4 19
575 60 66 100 70 70 12.8 80 12.8 80
— —
2 2.9 15.3
3050T
208 60 248 400 250 250 51.3 300 51.3 300
— —
2 7.6 44
230 60 248 400 250 250 51.3 300 51.3 300 — — 2 7.4 37
380 60 137 200 150 150 28 139 28 139 — — 2 4.5 23.1
460 60 114 150 125 125 23.1 150 23.1 150 — — 2 4 19
575 60 96 150 110 110 19.9 109 19.9 109
— —
2 2.9 15.3
3055T
208 60 276 400 300 300 57.7 284 57.7 284
— —
2 7.6 44
230 60 275 400 300 300 57.7 330 57.7 330 — — 2 7.4 37
380 60 149 200 175 175 30.9 192 30.9 192 — — 2 4.5 23.1
460 60 130 200 150 150 26.9 180 26.9 180 — — 2 4 19
575 60 103 150 110 110 21.5 132 21.5 132
— —
2 2.9 15.3
3060T
208 60 306 400 350 350 48.5 249 48.5 249 48.5 249 2 7.6 44
230 60 305 400 350 350 48.5 288 48.5 288 48.5 288 2 7.4 37
380 60 170 250 200 200 27.6 159 27.6 159 27.6 159 2 4.5 23.1
460 60 150 200 175 175 24.4 145 24.4 145 24.4 145 2 4 19
575 60 112 150 125 125 17.4 109 17.4 109 17.4 109 2 2.9 15.3
3070T
208 60 334 400 350 350 48.5 249 48.5 249 48.5 249 2 7.6 44
230 60 333 400 350 350 48.5 249 48.5 249 48.5 249 2 7.4 37
380 60 191 250 225 225 27.6 159 27.6 159 27.6 159 2 4.5 23.1
460 60 169 200 175 175 24.4 145 24.4 145 24.4 145 2 4 19
575 60 120 150 125 125 17.4 109 17.4 109 17.4 109 2 2.9 15.3
3075T
208 60 363 600 400 400 57.7 284 57.7 284 57.7 284 2 7.6 44
230 60 363 600 400 400 57.7 330 57.7 330 57.7 330 2 7.4 37
380 60 201 250 225 225 30.9 192 30.9 192 30.9 192 2 4.5 23.1
460 60 177 250 200 200 26.9 180 26.9 180 26.9 180 2 4 19
575 60 134 200 150 150 21.5 132 21.5 132 21.5 132 2 2.9 15.3
3079T
208 60 363 400 400 400 57.7 284 57.7 284 57.7 284 2 7.6 44
230 60 363 400 400 400 57.7 330 57.7 330 57.7 330 2 7.4 37
380 60 201 250 225 225 30.9 192 30.9 192 30.9 192 2 4.5 23.1
460 60 177 250 200 200 26.9 180 26.9 180 26.9 180 2 4 19
575 60 134 200 150 150 21.5 132 21.5 132 21.5 132 2 2.9 15.3
3085T
208 60 391 600 450 450 57.7 284 57.7 284 57.7 284 2 7.6 44
230 60 390 600 450 450 57.7 330 57.7 330 57.7 330 2 7.4 37
380 60 211 250 250 250 30.9 192 30.9 192 30.9 192 2 4.5 23.1
460 60 184 250 200 200 26.9 180 26.9 180 26.9 180 2 4 19
575 60 146 200 150 150 21.5 132 21.5 132 21.5 132 2 2.9 15.3
Notes:
• Reference PIN 59 for pump models.
• Use this table along with Table 9 on page 58 to determine electrical data of the unit plus the pump.
• Does not include the control transformer.
