Table 39: R-454B pressure temperature chart
psig Temperature, ˚F psig Temperature, ˚F
0 – 78 25
2 – 80 26
4 -49 85 29
6 -45 90 32
8 -41 95 34
10 -37 100 37
12 -34 105 39
14 -31 110 42
16 -28 115 44
18 -26 120 46
20 -23 125 48
22 -21 130 51
24 -18 135 52
26 -16 140 54
28 -14 145 56
30 -12 150 58
32 -10 160 60
34 -8 170 66
36 -6 180 69
38 -4 190 72
40 -2 200 76
42 – 210 79
44 1 220 82
46 3 225 83
48 4 235 86
50 6 245 89
52 8 255 91
54 9 265 94
56 11 275 95
58 12 285 99
60 13 295 101
62 15 305 103
64 16 325 108
66 17 355 114
68 19 375 118
70 20 405 124
72 21 500 140
74 22 600 –
76 24 700 –
